Accucold - 20" Built-In Covid Vaccine Freezer, ADA Compliant ADA305AF

20" Wide Built-In Covid Vaccine All-Freezer, ADA Compliant

Documentation:

Please advise Documentations above for an easy experience - Recommended Saving User's Manual for Future Reference - READ ALL INSTRUCTIONS BEFORE USE

Accucold offers a quality selection of 20" wide built-in undercounter all-freezers designed for installation under lower ADA compliant counters, with advanced features for the safe storage of select vaccines, pharmaceuticals, and other materials with strict storage conditions

Features:

- ADA Compliant Design - 32" Height Allows Easy Installation Under Lower Counters
- Built-In Capable - Front-Breathing Design Lets You Make the Best use of Space by Installing Your Appliance Under the Counter
- (-25) Degrees C Capable - Low Temperature Operation Ideal for Vaccines, Pharmaceuticals, and Other Sensitive Materials
- Factory-Installed Lock - Located at Top of the Door for Easy Access and Security (2 Keys Included)
- Access Port - Unit Comes W/Factory Installed Probe Hole for Users to Connect their Own Equipment
- Adjustable Digital Thermostat - Readout in Fahrenheit or Celsius
- Basket Shelves - (3) Slide-Out Baskets Offer Convenient Storage W/Plastic Fronts to Protect Contents from Warmer Air
- 3" Thick Door - Improved Insulation for an Efficient Performance
- Note: Due to the oversized design, the door does not open in its own radius. If installing this freezer against a wall, please see our drawings to ensure adequate space
- Reversible Door - User-Reversible Door Swing to Best Accommodate Your Setting
- Temperature Alarms - User-Set High/Low Temperature Alarms Provide Added Security if Temp. Goes Beyond Setpoint
- Open Door Alarm - Audible Alarm Will Sound if the Door is Left Ajar for Over a Minute
- Hospital Grade Cord with 'Green Dot' Plug - Secure Three-Pronged Cord for Added Unit Safety
- Manual Defrost - More Temperature Stability W/an Energy Efficient Manual System
- Flat Door Liner - Ensures Stable Conditions for Sensitive Materials
- No Internal Fan - Temperature Remains More Stable W/a Static Cooling System
- Sealed Back - Space-Saving Design that Offers Easier Cleanability
- Interior Light - Front-Located LED Light Ensures Entire Interior is Lit When Door Opens
- Magnetic Door Gasket - Ensures a Tight Seal for Energy Savings & Improved Performance
- Matching All-Refrigerator - Can Be paired with the ADA404REF All-Freezer for a Complete Set
- Fully Finished White Cabinet - Allows the Unite to be Freestanding
- *100% CFC Free - Environment Friendly Design W/Out Ozone-Damaging Chemicals
- *CARB Compliant - Hydrocarbon-Based Refrigerant for A Greener Footprint

Specifications: (Better Detailed in Brochure)

- HxW - 31.75" (81cm), - Height to Hinge Cap - 32.0" (81cm) x 19.75" (50cm) - Width W/Door Open - 20.25" (51cm)
- Depth - 22.5" (57cm) - Depth W/Handle - 24.38" (62cm) - Depth W/Door @ 90° - 40.25" (102cm)
- Capacity - 2.47 Cu.Ft. (70L)
- Defrost Type - Manual
- Door - White
- Cabinet - White
- Amps - 1.1
- Voltage/Frequency - 115 V AC/60 Hz
- Weight - 65.0 lbs. (29kg) - Shipping Weight - 73.0 lbs (33kg)
- Parts & Labor Warranty - 1 Years - Compressor Warranty - 5 Years
- US Electrical Safety - ETL - Canadian Electrical Safety - ETL-C
- UPC - 761101063065

Interior Dimensions - (Height x Width x Depth)

- 23.5" (60cm) x 14.5" (37cm) x 17.0" (43cm)
- Compressor Step - 5.75" (15cm) x 14.5" (37cm) x 6.0" (15cm)

Freezer Features:

- RHD Door Swing
- Factory Reversible
- Digital Thermostat
- Exterior Fan
- Holds 1.34 oz. / R600a Refrigerant
- High Side PSI - 180.0
- Level Legs - Qty 2
- Low Side PSI - 80.0
- Interior Drawers - Qty 3
- Temperature Range - (-25°) to (-15°C)


NOTE: Accucold freezers are purpose-built to the support meeting the current CDC (Centers for Disease Control) guidelines for the

storage of vaccines. As referenced in the current Vaccine Storage and Handling Toolkit, these units incorporate several key features for

stable operation. For additional temperature assurance, the CDC recommends a calibrated digital data logger (DDL), which can be

added with the factory-installed option DL2B or addition of the DL2BKit accessory. Select Accucold products have been tested and

certified to the new NSF 456 standard, and are now available for purchase. For additional information, contact our products specialists.
